Self-Testing, Class 2 output
|
Model #
|
12NC
|
|
BSL17CC2ST
|
913702462301
|
|
UL Listed for US and Canada
|
Listed to UL924 and tested to CSA 22.2, No. 141
For Field or Factory Installation (Indoor and Damp) |
|
Illumination Time
|
90 Minutes
|
|
Full Warranty
|
5 Years (NOT pro-rata)
|
|
Universal Input Voltage
|
120-277 VAC, 50/60 Hz
|
|
AC Input Current
|
3.0 W (Maximum)
|
|
AC Input Power Rating
|
2.75 W
|
|
Output Voltage
|
15.0 - 50.0 VDC
|
|
Output Power
|
7.5 W (Maximum)
|
|
Test Switch/Charging Indicator Light
|
2 W - ITS (2-Wire illuminated test switch)
|
|
Battery
|
High-Temperature,
Maintenance-Free Nickel-Cadmium Battery 7- to 10-Year Life Expectancy |
|
Recharge Time
|
24 Hours
|
|
Temperature Rating (Ambient)
|
Ambient : 0°C to +50°C (32°F to 122°F) Case: Tc (max): 65°C
|
|
Dimensions
|
12.0" x 2.4" x 1.5"
(304 mm x 60 mm x 38 mm) Mounting Center 11.5" (292 mm) |
|
Weight
|
4.3 lbs. (1.95 kg)
|
