Battery Backup, Universal Mount
Red or Green Lettering
FirstLink Compatible for Automated Testing and Reporting
UL Listed
Battery Backup, Universal Mount
Red or Green Lettering
FirstLink Compatible for Automated Testing and Reporting
UL Listed
|
Model #
|
12NC
|
|
BXAGWFL1 BXARWFL1 |
929002756913 929002757013 |
|
UL LISTED FOR US & CANADA
|
Listed to UL 924 for Field Installation in the US and Canada (Indoor and Damp) DOE Compliant |
|
Illumination Time
|
90 Minutes
|
|
Full Warranty
|
5 Years (NOT pro-rata)
|
|
Universal Input Voltage
|
120-277 VAC, 50/60 Hz
|
|
Construction
|
White thermoplastic housing UL94 5VA Flame Rated, UV stable Contractor friendly snap together design Electronics and battery contained within housing |
|
Installation
|
Universal wall/end/ceiling mounting (universal mounting adapter provided for wall and end mounting) Back plate keyhole slots are easily removable knockouts for securing to a 3" or 4" j-box Pop-out directional indicating chevrons easily removed as required Extra stencil face plate provided for double faced applications |
|
Battery
|
High-Temperature, Maintenance-Free
Lithium-Ion Battery 7- to 10-Year Life Expectancy |
|
Recharge Time
|
24 Hours
|
|
Temperature Rating (Ambient)
|
50° F to 104° F (10° C to 40° C)
|
|
Dimensions
|
8.7" H x 13.75" W x 2.13" D (220mm x 350mm x 255mm)
|
|
Weight
|
2.6 lbs (1.18 kg)
|
