Sinusoidal output provides 185 VA max emergency power for 2 hours
Connected lighting load greater than 185 VA when using patented Autodim (0-10V)
CEC Title 20 and self-testing
Sinusoidal output provides 185 VA max emergency power for 2 hours
Connected lighting load greater than 185 VA when using patented Autodim (0-10V)
CEC Title 20 and self-testing
|
Model #
|
12NC
|
|
ELIS185I2UO30AD2HI
|
913702485601
|
|
UL Listed for the US and Canada
|
UL924 Emergency Lighting Compliant
For Field Installation (Indoor and Damp) |
|
Maximum Output Power
|
185 VA
|
|
Total Connected Output Load
|
Dimmable lighting loads: 800 W Maximum Input Power
Non-Dimmable lighting loads: 185 VA Maximum Input Power |
|
Illumination Time
|
120 Minutes
|
|
AC Input Voltage
|
120 VAC, 60 Hz or 277 VAC, 60 Hz
|
|
AC Input Current
|
1000 mA Max, 120Vac or
360 mA Max, 277Vac |
|
Battery
|
2 ea. required
12V (nominal), 35Ah Maintenance-Free Sealed Lead Acid Battery |
|
Recharge Time
|
24 Hours
|
|
Charging Indicator Light / Test Switch
|
Illuminated Test Switch (Charge Indicator LED / Test Switch)
|
|
Output Voltage, Automatically Selected
|
120 VAC +/- 10%, or 277 VAC +/- 10%
|
|
Output Frequency
|
60 Hz, ± 5%
|
|
Temperature Rating (Ambient)
|
68° F to 86° F (20° C to 30° C)
|
|
Dimensions
|
12.0” H x 12.5” W x 10.0” D
(317mm x 305mm x 254mm) |
|
Weight
|
Enclosure and Electronics only: 16 lbs. (7.26 kg)
Batteries: 23.15 lbs each; 46.3 lbs (21 kg) total |
|
Warranty
|
5 Years (not including batteries)
3 Year Battery warranty, plus 7 years additional pro-rating |
