14-Watts Output Power
Multiple Configurations Available
Self-Testing
Multiple Configurations Available
Self-Testing
|
Model #
|
12NC
|
|
BSL14B2UAK55C1I1
|
913702487101
|
|
BSL14B2UAK55L1I1
|
913702487301
|
|
BSL14B2UCK55C1I1
|
913702487501
|
|
BSL14B2UCK55L1I1
|
913702487701
|
|
BSL14B6UAK55SBI1
|
913702487801
|
|
BSL14B2UAK55C1BAI1
|
913702491601
|
|
BSL14B2UAK55DFI1
|
913702492401
|
Variations:
Class 2 or High Output Voltage
With or Without Conduit
Integral or Separate Battery
|
UL Listed for US and Canada
|
Listed to UL924 and tested to CSA 22.2 No. 141
For Field or Factory Installation (Indoor and Damp) |
|
Illumination Time
|
90 Minutes
|
|
Full Warranty
|
5 Years (NOT pro-rata)
|
|
Universal Input Voltage
|
120-277 VAC, 50/60 Hz
|
|
AC Input Current
|
100 mA Maximum
|
|
Output Voltage
|
15-54 Vdc or 54-200 Vdc
|
|
Output Power
|
14.0 W
|
|
Test Switch/Charging Indicator Light
|
IP65 rated for ingress protection to dust and water jets. Test Switch Assembly is UL2043 Plenum-Rated. |
|
Battery
|
High-Temperature, Maintenance-Free LFP Battery Technology |
|
Recharge Time
|
24 Hours
|
|
Temperature Rating
|
Ambient: 0°C to +55°C (32°F to 131°F) Case: Tc (Max): 65°C |
|
Dimensions
|
B2 Enclosure: 15.34” x 2.25” x 1.18” (369 mm x 58 mm x 30 mm) Mounting Center 15.0” (356 mm) B6 Enclosure: 9.37” x 2.20” x 1.05” (238mm x 55.9mm x 26.7mm) Mounting Center 8.9” (226mm) |
|
Weight
|
BSL14B2: With Conduit – 3.00 lbs Without Conduit – 2.60 lbs BSL14B6: 1.95 lbs |
