IHB Series

Two pendant lights hanging side by side. The left pendant light features a white dome with a soft, warm glow, while the right pendant light is black with a reflective inner surface, giving a more focused, diffused light.

A Modern Twist on Classic Industrial Lighting

Illuminate your space with the Lightolier 3D Printed Decorative High Bay, an innovative fixture that reimagines classic industrial lighting with sleek, modular options. Lightweight yet durable, it’s easy to install and customize with a variety of colors and styles to match your vision.

Crafted from sustainable materials and proudly printed and assembled in Littlestown, PA, this high bay offers multiple high-intensity lumen packages, making it ideal for big-box retail, grocery stores, car dealerships, and other high-ceiling applications.

Configuration

Downloads

Application Imagery

Key specifications

Configurable with three styles, two sizes, and dozens of color and texture combinations
Selectable lumen packages for 10,000 - 33,000 lm
Efficacy up to 143 lm/W
Standard CRI 90 with 3500K and 4000K CCT options
Hook mount provided, bracket mount and stem adapter available to order
0-10V dimming
Declare Label - LBC Red List Approved
DLC Listed, some configurations are DLC Premium
Lifetime L7B50 at >54,000 hours.
Printed and assembled in Littlestown, PA
Buy American Act (BAA) compliant

Schematic light drawing

Operational & certifications

Protection Class	IP20, IK05
Ambient Range	0 to +35C
Certifications	cULus, RoHS, Declare, DLC Listed, DLC Premium on some configurations
Warranty	5 Years
